Step Stencils for Mixed Component Height and Paste Volume Needs
XFPCB supports step stencils when a PCB assembly needs different solder paste volumes for fine-pitch and large components on the same board.
XFPCB Step Stencil Service
XFPCB supports Step Stencil for SMT projects that need stable solder paste printing. We help confirm stencil thickness, aperture design, frame option and special areas for fine-pitch components or mixed paste-volume requirements.
For stencil work, provide paste Gerber, panel data, component density and any fine-pitch or large thermal-pad areas. XFPCB will help choose stencil thickness and aperture strategy for stable paste printing.
For Step Stencil, XFPCB combines engineering review, manufacturing preparation, quality inspection and export communication so your purchasing team can move from RFQ to delivery with a clear build plan.
Order Workflow
Stencil Design
Choose stencil thickness, frame and special aperture strategy.
Stencil Production
Manufacture the stencil for prototype or production use.
Future Revisions
Use assembly feedback to tune future stencil revisions.
How XFPCB Controls the Build
- Paste Gerber, aperture areas, fiducials and panel data are checked before stencil production.
- Stencil thickness is selected according to component pitch and paste volume requirements.
- Step, nano-coating or electroform options are applied when the assembly needs tighter paste control.
- Stencil files and production notes are kept for repeat assembly orders.
Quotation Details
| Project Area | XFPCB Guidance |
|---|---|
| Use case | Boards mixing small QFN or BGA with larger terminals or shields |
| Design need | Clear step area drawing |
| Assembly value | Reduce opens and bridges caused by one stencil thickness |
step-up and step-down areas
XFPCB reviews step-up and step-down areas against your submitted files, quantity and application requirements before confirming the build plan.
fine-pitch ICs
Clear fine-pitch ICs requirements help our team quote accurately, prepare production data and reduce avoidable clarification rounds.
large connectors
Our engineers confirm details for large connectors early, so your team can approve the order with clear next steps.
Useful Terms
- Aperture
- The stencil opening that controls paste deposit.
- Step-up
- A thicker stencil area for more paste.
- Step-down
- A thinner area for fine-pitch parts.
- Paste release
- How cleanly paste leaves the stencil opening.
